CABLE LUG
“Premium-grade electrolytic tinned copper cable lug ($70\text{ mm}^2$ with M10 bolt hole). Features a heavy-duty seamless barrel design for optimal mechanical crimping. Engineered to deliver maximum electrical conductivity and superior corrosion resistance for low and medium-voltage power terminations across Saudi Arabia.”
Description
Overview
Our Heavy-Duty Tinned Copper Cable Lugs are precision-manufactured from high-purity, seamless electrolytic copper tubing to ensure the highest standard of electrical connectivity. The entire surface is electro-tin plated to guard against atmospheric oxidation and galvanic corrosion, making them ideal for the harsh, high-ambient temperature environments common in industrial installations throughout the Kingdom. Designed with an inspection window, these lugs allow quality inspectors to instantly verify complete cable insertion before crimping.
Key Features & Benefits
-
99.9% Pure Electrolytic Copper: Provides maximum electrical conductivity, significantly reducing resistance and heat generation at critical termination points.
-
Electro-Tin Plating: Offers long-term protection against corrosion, moisture, and oxidation—crucial for coastal and outdoor industrial applications.
-
Annealed Barrel Design: The copper is specially annealed to prevent cracking, splitting, or structural failure when subject to heavy mechanical stress from hydraulic crimping tools.
-
Easy Wire Entry: Features a flared, chamfered barrel entrance to ensure smooth and fast insertion of stranded or flexible copper conductors, speeding up assembly times on-site.
⚙️ Technical Specifications Table
(Paste this into your Main Description box or input it via your WooCommerce Attributes tab to build a clean technical datasheet).
| Specification Parameter | Technical Detail |
| Product Type | Compression Cable Lug / Terminal End |
| Material | High-Purity Electrolytic Copper (Grade Base) |
| Surface Finish | Electro-Tinned Plated |
| Barrel Type | Heavy-Duty Seamless Tube (With Inspection Window) |
| Conductor Size (Cross Section) | $70\text{ mm}^2$ |
| Stud / Bolt Hole Size | M10 ($10\text{ mm}$ clearing hole) |
| Voltage Rating | Suitable for Low Voltage up to $3.3\text{ kV}$ (and Medium Voltage applications) |
| Termination Method | Hexagonal or Indent Hydraulic Crimping |
| Working Temperature | Continuous up to $+120^\circ\text{C}$ |
| Standards Compliance | BS 4579, IEC 61238, SASO Quality Standards |
