Contactor Schneider
“High-reliability Schneider Electric TeSys Deca (formerly TeSys D) 3-Pole Magnetic Contactor. Rated for 32A (AC-3, 400V) and 15kW motor control applications. Features a high-performance 220V AC control coil and built-in auxiliary contacts ($1\text{ NO} + 1\text{ NC}$), engineered for heavy-duty industrial motor switching and HVAC automation systems.”
Description
Overview
The Schneider Electric TeSys Deca series (the global evolution of the legendary TeSys D range) sets the premium industry standard for motor control and power switching efficiency. This 3-pole magnetic contactor is optimized for $AC-1$ (resistive) and $AC-3$ (inductive motor) load categories. Engineered to drop seamlessly into motor starters, control panels, and automation systems, it ensures exceptionally long electrical and mechanical life under heavy cycling demands.
Key Features & Benefits
-
High Electrical Integrity: Built with robust, wear-resistant silver-alloy contacts that provide stable connection paths and suppress electrical arcing during high-current switching.
-
Integrated Auxiliary Contacts: Comes standard with $1\text{ NO}$ (Normally Open) and $1\text{ NC}$ (Normally Closed) auxiliary contacts, simplifying control circuit feedback wiring without needing extra add-on blocks.
-
EcoStruxure Connected Ready: Features multi-standard screw clamp terminals that guarantee secure, vibration-proof wire terminations even over extended operational lifespans.
-
Comprehensive Safety Certifications: Fully certified by global testing bodies and fully compliant with SASO regulations for immediate deployment across commercial and industrial infrastructure in the Kingdom.
⚙️ Technical Specifications Table
(Paste this into your Main Description box or input it via your WooCommerce Attributes tab to build a clean technical datasheet).
| Specification Parameter | Technical Detail |
| Brand | Schneider Electric |
| Range / Series | TeSys / TeSys Deca (TeSys D) |
| Product Type | Magnetic Contactor |
| Device Short Name | LC1D32M7 |
| Poles Description | 3P (3-Pole, 3 Power Contacts) |
| Utilization Category |
AC-3 (Inductive loads / Motor control)
AC-1 (Resistive loads / Heating) |
| Rated Operational Current ($I_e$) |
32 A at $\le 440\text{ V AC}$ (AC-3)
50 A at $\le 440\text{ V AC}$ (AC-1) |
| Motor Power (kW) | 15 kW at $380/400\text{ V AC}$ $50/60\text{ Hz}$ |
| Control Circuit Voltage ($U_c$) | 220 V AC $50/60\text{ Hz}$ |
| Auxiliary Contact Composition | $1\text{ NO} + 1\text{ NC}$ (Built-in) |
| [Rated Insulation Voltage] ($U_i$) | 690 V conforming to IEC 60947-4-1 |
| Mounting Support | Rail (35mm standard DIN Rail) or Plate/Panel mount |
| Standards Compliance | IEC 60947-4-1, EN 60947-5-1, CE Certified, SASO Approved |
Additional information
| VOLTAGE | 110V, 12V, 220V, 24V, 415V |
|---|
